S E R I A L C O N T R O L M O D U L E : U A R T
ARM Wakeup Control register
www.digiembedded.com
403
Register
Register bit
assignment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A R M W a k e u p C o n t r o l r e g i s t e r
Address: 9001_1030 / 9001_9030 / 9002_1030 / 9002_9030
Use the ARM Wakeup Control register to enable the ARM wakeup control logic.
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Not used
Not used
EN
ABLE BUSY
CHAR
Bits
Access
Mnemonic
Reset
Description
D31
R/W
ENABLE
0
Force transmit enable
Use this field to force the transmitter to send the character
specified in the CHAR field (D07:00). All user-specified
rules, such as bit order, parity, or number of stop bits, are
enforced.
Write a 1 to enable this field. Hardware clears the field
once the character has been transmitted. Writing a 1 to this
field when it is already a 1 has unpredictable results.
Note:
Writing a 1 to this field also clears the FORCE
field in the Interrupt Status register.
D30
R
BUSY
0
Read-only busy
Reading a 1 indicates that the force operation you initiated
is in progress.
D29:08
R
Not used
0
Write this field to 0.
D07:00
R/W
CHAR
0
Force character
Defines the character that is forced out of the transmitter.
