2 Installation
732 IC Detector / 733 IC Separation Center
26
2 Installation of the capillary in the IC Separation
Center
•
Unscrew the four knurled screws 37
37 of the bottom rear panel
39
39 of the 733 IC Separation Center and remove rear panel
(see Fig. 5).
•
Insert steel capillary 71
71 from the back into the inner com-
partment of the IC Separation Center.
•
Install rear panel 39
39 so that the capillary is positioned in
opening 40
40 „Inlet A“ or 44
44 „Inlet B“ and screw on with the four
knurled screws 37
37.
3 Connection to injection valve
•
Connect steel capillary 71
71 to pulsation dampener 66
66 (see
section 2.6.2). Using another steel capillary 71
71, connect pul-
sation dampener 66
66 to connection "5" of injection valve 68
68.
4 Mount column connection capillary
•
Connect column connection capillary 67
67 (ca. 20 cm of
6.1831.010 PEEK capillary) to connection "4" of injection valve
68
68.
709
56
56
70
70
733
71
71
69
69 63
63
71
71 66
66 67
67
68
68
Fig. 14: Connection to injection valve with steel capillaries
56
56
Inlet capillary
of Filter unit Manufit 69
69
68
68
Injection valve
63
63
Outlet capillary
of Filter unit Manufit 69
69
69
69
Filter unit Manufit (6.2821.000)
66
66
Pulsation dampener (6.2620.150)
70
70
Coupling (6.2620.060)
67
67
Column connection capillary
6.2620.020 Steel capillary
71
71
Steel capillary (6.2620.020)
