7.1 Technical data
732 IC Detector / 733 IC Separation Center
191
Interfaces
RS232 interfaces Specifications, see section 6.1
Remote interfaces Specifications, see section 6.2
Analog output Specifications, see section 6.3
Safety specifications
Construction/testing According to IEC 1010 / EN 61010 / UL 3101-1,
protection class 1, degree of protection IP40
Safety directions The Instructions for Use include information and
warnings which must be heeded by the user to
assure safe operation of the instrument.
Electromagnetic compatibility (EMC)
Emitted interference Standards met:
EN 55011 (class B), EN 55022 (class B),
EN 50081-1/2
Immunity to interference Standards met:
IEC801-2/IEC1000-4-2 (class 4), IEC801-3/
IEC1000-4-3 (class 3), IEC801-4/IEC1000-4-4
(class 4), IEC801-5/IEC1000-4-5 (class 2/3),
IEC801-6/IEC1000-4-6 (class 3), EN50082-2,
EN61000-3-2/3/IEC1000-3-2/3, EN50093/
IEC1000-4-11
Ambient temperature
Nominal operating range +5 … +45°C
(at 20 … 80 % atmospheric humidity)
Storage, transport –20 … +70°C
Diagnostic tests
Self-diagnostic test Automatic self-diagnosis when instrument
switched on
User diagnostic test Built-in diagnostic program (see section 5.4)
Housing
Material of cover Polyurethane rigid foam (PUR) with fire protection
for fire class UL94VO, FCH-free
Material of base Steel, enameled
Width 255 mm
Height 130 mm
Depth 343 mm
Weight 8.2 kg (with detector block, without accessories)
