Metrohm 732 IC Detector - Manual (Page 132)

4.8 Data output
732 IC Detector / 733 IC Separation Center
125
Example of "event" report
Two daily events (adjust pump flow) and a
date event (switch off pump supply)
EVENT
daily: 07:00:00
pump flow 2.00 mL/min
daily: 19:00:00
pump flow 0.30 mL/min
date: 95-10-13 16:00:00
pump off
--------------
Example of "method" report
Method for the determination of drinking
water with PRP-X100 Anion Column
METHOD
method name PRP-X100
date: 1995-10-10 15:15:41
PARAM
>PARAM/detector
range: 200
µ S/cm
full scale: 4.00 µ S/cm
temp.coeff.: 2.5 %/°C
>PARAM/analog output
polarity: +
offset: 0 %fs
damping: off
>PARAM/plot
auto start: off
time interval 1.0 s
time scale 10.0 mm/min
time scale label: rel
stop time off min
left: 0.000
µ S/cm
right: 4.000 µ S/cm
>PARAM/709 IC Pump
flow 2.00 mL/min
Pmax 10.0 MPa
Pmin 1.0 MPa
flow corr. 1.00
PROGRAM
progr.typ inject
17.9 zero on
18.0 flag end
--------------
Example of "method list" report
Method list
method name 'PRP-X100'
progr.typ inject
date 1995-10-10 15:15:41
number of steps 3
free memory 8(9)
--------------
Example of "param" report
Measurement parameters for drinking
water determination with PRP-X100 IC
Anion Column
PARAM
>PARAM/detector
range: 200
µ S/cm
full scale: 4.00 µ S/cm
temp.coeff.: 2.5 %/°C
>PARAM/analog output
polarity: +
offset: 0 %fs
damping: off
>PARAM/plot
auto start: off
time interval 1.0 s
time scale 10.0 mm/min
time scale label: rel
stop time off min
left: 0.000
µ S/cm
right: 4.000 µ S/cm
>PARAM/709 IC Pump
flow 2.00 mL/min
Pmax 10.0 MPa
Pmin 1.0 MPa
flow corr.. 1.00
--------------
Example of "program" report
Program parameters for drinking water
determination with the PRP-X100 IC Anion
Column
PROGRAM
progr.type: inject
17.9 zero: on
18.0 flag: end
--------------
Example of "pump" report
Report of the parameters for the 709 IC
Pump
PUMP
status running
Pactual 6.9 MPa
error no error
--------------
