The table shows a description of the output for the show ip vrrp brief and show ip vrrp-extended
brief commands.
Output description for VRRP or VRRP-E summary information TABLE 127
Field Description
Total number of
VRRP (or VRRP-
Extended) routers
defined The total number of VRIDs configured on this Layer 3 switch.
NOTE
The total applies only to the protocol the Layer 3 switch is running. For example, if the
Layer 3 switch is running VRRP-E, the total applies only to VRRP-E routers.
Interface The interface on which VRRP or VRRP-E is configured. If VRRP or VRRP-E is configured
on multiple interfaces, information for each interface is listed separately.
VRID The VRID configured on this interface. If multiple VRIDs are configured on the interface,
information for each VRID is listed in a separate row.
CurPri The current VRRP or VRRP-E priority of this Layer 3 switch for the VRID.
P Whether the backup preempt mode is enabled. If the backup preempt mode is enabled,
this field contains a "P". If the mode is disabled, this field is blank.
State This Layer 3 switch VRRP or VRRP-E state for the VRID. The state can be one of the
following:
• Init - The VRID is not enabled (activated). If the state remains Init after you activate the
VRID, make sure that the VRID is also configured on the other routers and that the
routers can communicate with each other.
NOTE
If the state is Init and the mode is incomplete, make sure you have specified the IP address
for the VRID.
• Backup - This Layer 3 switch is a Backup for the VRID.
• Master - This Layer 3 switch is the Master for the VRID.
Master addr IP address of the router interface that is currently Master for the VRID.
Backup addr IP addresses of router interfaces that are currently Backups for the VRID.
VIP The virtual IP address that is being backed up by the VRID.
Displaying detailed information
To display detailed VRRP or VRRP-E information, enter the show ip vrrp command at any level of the
CLI.
device#show ip vrrp
Total number of VRRP routers defined: 1
Interface ethernet v3
auth-type simple text password
VRID 3
state master
administrative-status enabled
Displaying detailed information
