show ip bgp neighbors route-summary output descriptions (Continued)

TABLE 96

This field

Displays

Routes Advertised

The number of routes the device has advertised to this neighbor:

• To be Sent - The number of routes queued to send to this neighbor.
• To be Withdrawn - The number of NLRIs for withdrawing routes the device has

queued to send to this neighbor in UPDATE messages.

NLRIs Sent in
Update Message

The number of NLRIs for new routes the device has sent to this neighbor in UPDATE
messages:

• Withdraws - Number of routes the device has sent to the neighbor to withdraw.
• Replacements - Number of routes the device has sent to the neighbor to replace

routes the neighbor already has.

Peer Out of Memory
Count for

Statistics for the times the device has run out of BGP4 memory for the neighbor during
the current BGP4 session:

• Receiving Update Messages - The number of times UPDATE messages were

discarded because there was no memory for attribute entries.

• Accepting Routes (NLRI) - The number of NLRIs discarded because there was no

memory for NLRI entries. This count is not included in the Receiving Update
Messages count.

• Attributes - The number of times there was no memory for BGP4 attribute entries.
• Outbound Routes (RIB-out) - The number of times there was no memory to place a

"best" route into the neighbor route information base (Adj-RIB-Out) for routes to be
advertised.

Displaying BGP4 neighbor information

You can display configuration information and statistics for BGP4 neighbors of the device.

To view BGP4 neighbor information, including the values for all the configured parameters, enter the
following command.

NOTE
The display shows all the configured parameters for the neighbor. Only the parameters that have values
different from their defaults are shown.

device(config-bgp)# show ip bgp neighbor 10.4.0.2

Total number of BGP neighbors:

1 IP Address: 10.4.0.2, AS: 5 (EBGP), RouterID: 10.0.0.1

Description: neighbor 10.4.0.2

Local AS: 101

State: ESTABLISHED, Time: 0h1m0s, KeepAliveTime: 0, HoldTime: 0

PeerGroup: pg1

Multihop-EBGP: yes, ttl: 1

RouteReflectorClient: yes

SendCommunity: yes

NextHopSelf: yes

DefaultOriginate: yes (default sent)

MaximumPrefixLimit: 90000

RemovePrivateAs: : yes

RefreshCapability: Received

Route Filter Policies:

Distribute-list: (out) 20

Filter-list: (in) 30

Prefix-list: (in) pf1

Route-map: (in) setnp1 (out) setnp2

Messages: Open Update KeepAlive Notification Refresh-Req

Sent : 1 1 1 0 0
