The match protocol bgp external option will match the eBGP routes.
The match protocol bgp internal option will match the iBGP routes.
The match protocol bgp static-network option will match the static-network BGP4 route, applicable
at BGP4 outbound policy only.
Matching based on interface
The match option has been added to the route-map command that distributes any routes that have
their next hop out one of the interfaces specified. This feature operates with the following conditions:
• The match interface option can only use the interface name (for example ethernet 1/2) and not the
IP address as an argument.
• The match interface option is only effective during redistribution and does not apply for other route
map usage such as: bgp outbound route update policy.
• The match interface option can be applied to other types of redistribution such as redistributing
OSPF routes to BGP4, or filtering out all OSPF routes that point to a specific interface.
To configure the match-interface option, use the following command.
device(config)# route-map test-route permit 99
device(config-routemap test-route)# match interface ethernet 1/1 eth 3/2
device(config-routemap test-route)# exit
Syntax: [no] match interface interface interface ...
The interface variable specifies the interface that you want to use with the match interface command.
Up to 5 interfaces of the following types can be specified:
• ethernet slot/port
• loopback loopback-number
• null0
• tunnel tunnel-ID
• ve ve-ID
Setting parameters in the routes
Use the following command to define a set clause that prepends an AS number to the AS path on
each route that matches the corresponding match statement.
device(config-routemap GET_ONE)# set as-path prepend 65535
Syntax: [no] set [ as-path [ prepend as-num,as-num,... ] ] | [ automatic-tag ] | [ comm-list acl
delete ] | [ community num : num | num | additive | local-as | no-advertise | no-export ] | [
dampening [ half-life reuse suppress max-suppress-time ] ] [ ip next hop ip-addr ] [ ip next-hop
peer-address ] | [ local-preference num ] | [ metric [ + | - ] num | none ] | [ metric-type type-1 |
type-2 ] | external [ metric-type internal ] | [ next-hop ip-addr ] | [ origin igp | incomplete ] | [ tag ] |
[ weight num ]
The as-path prependnum,num,... parameter adds the specified AS numbers to the front of the AS-
path list for the route. The range of num values is 1 - 65535 for two-byte ASNs and 1 - 4294967295 if
AS4s have been enabled.
The automatic-tag parameter calculates and sets an automatic tag value for the route.
NOTE
This parameter applies only to routes redistributed into OSPF.
