CLI display of IP traffic statistics - Layer 3 switch (Continued) TABLE 26
Field Description
responses sent The number of responses this device has sent to another RIP router request for
all or part of this device RIP routing table.
responses received The number of responses this device has received to requests for all or part of
another RIP router routing table.
unrecognized This information is used by Brocade customer support.
bad version The number of RIP packets dropped by the device because the RIP version
was either invalid or is not supported by this device.
bad addr family The number of RIP packets dropped because the value in the Address Family
Identifier field of the packet header was invalid.
bad req format The number of RIP request packets this router dropped because the format was
bad.
bad metrics This information is used by Brocade customer support.
bad resp format The number of responses to RIP request packets dropped because the format
was bad.
resp not from rip port This information is used by Brocade customer support.
resp from loopback The number of RIP responses received from loopback interfaces.
packets rejected This information is used by Brocade customer support.
Displaying IP information - Layer 2 Switches
You can display the following IP configuration information statistics on Layer 2 switches:
• Global IP settings
• ARP entries
• IP traffic statistics
Displaying global IP configuration information
To display the Layer 2 switch IP address and default gateway, enter the show ip command.
device# show ip
Switch IP address: 192.168.1.2
Subnet mask: 255.255.255.0
Default router address: 192.168.1.1
TFTP server address: None
Configuration filename: None
Image filename: None
Syntax: show ip
This display shows the following information.
Displaying IP information - Layer 2 Switches
