Chapter 2 Product Overview and Troubleshooting 2-17
FIGURE 2-12 Operator Panel Location (at the Front of M8000)
2.3.2 Appearance and Operations
The operator panel can be used while the front door of the server is closed. Field
engineers, and the system administrator use the operation panel to check the
operating state of the server and to perform system power operations. To check the
operating state of the server, look at the LEDs. The operating state of the server is
checked by observing the LEDs, and the power supply is operated with the POWER
switch.
FIGURE 2-13 shows the appearance of the operator panel.
OPNL
