Appendix A System Configuration A-3
TABLE A-1 System Configuration for SPARC Enterprise M8000 Server
Unit Number Comments
Cabinet 1
CMU 1 to 4
CPU module 2 or 4
• In case of SPARC64 VI processor
2.28 GHz, L2 cache 5M bytes
2.4 GHz, L2 cache 6M bytes
Two CPU cores per CPU chip
Two threads per CPU core (four threads per CPU
module)
Maximum of 64 threads per system
• In case of SPARC64 VII processor
2.52 GHz, L2 cache 6M bytes
2.88 GHz, L2 cache 6M bytes
Four CPU cores per CPU chip
Two threads per CPU core (eight threads per CPU
module)
Maximum of 128 threads per system
Memory module (DIMM) 16 or 32
1 rank:DIMM-1GB, DIMM-2GB, DIMM-4GB
2 rank:DIMM-2GB, DIMM-4GB, DIMM-8GB
In case of DIMM-2GB, the maximum is
256 GB/system.
IOU 1 to 4
PCI cassette (card feeding adaptor) 8
At maximum, 32 cassettes per system
Slot#0, 2, 4, 6: PCI-EX short cards or IOU onboard
device cards
Slot#1, 3, 5, 7: PCI-EX short cards or link cards
