6-42 SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
2. Perform the above operation in reverse order to mount the DIMM.
Note – To mount DIMM, position the notch of DIMM to the corresponding part of
the connector.
FIGURE 6-23 Notch of DIMM
