13-16 SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
13.3 Hot Replacement
The procedure for hot replacement is as follows.
1. Unlock and open a door of the server.
For details, see Chapter 5 .
2. Turn off power to the relevant domain.
From a console that is connected to XSCF, log in to XSCF, and execute the
poweroff -d
command.
The shutdown processing is executed for the relevant domain, and then the
power-off processing is executed.
3. Confirm that the power-off processing is completed by confirming that the
POWER LED (green) on the PCI card is off.
4. Connect the wrist strap clip to a cabinet grounding port, and attach the band of
the wrist strap to one of your wrists.
5. Remove the PCI cassette of the PCI card to be replaced. (See FIGURE 13-2 )
Caution – To disconnect the link cable, which is a cable connected between the link
card mounted on the server and external I/O expansion unit, pull the latch lock of
the connector. If you forcibly pull the connector or the cable, the cable may be
damaged.
Caution – When removing cables such as LAN cable, if your finger can't reach the
latch lock of the connector, press the latch with a flathead screwdriver to remove the
cable. Forcing your finger into the clearance can cause damage to the PCI card.
a. Using a Phillips screwdriver, loosen the green screw securing the lever.
b. While grasping the upper part of the PCI cassette, pull the lever until it is
stopped, and continue pulling it to pull out the PCI cassette.
c. Place the removed PCI cassette on an antistatic conductive mat.
6. Remove the PCI card from the PCI cassette. (Perform the work on the
conductive mat.)
a. While grasping the lock bracket, turn it in the direction of the arrow and
push the lever a little. Then, push in the lever completely. (See FIGURE 13-3 )
Once you start moving the lever, the lock bracket need not be held.
