4-28 SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
4.5.2.1 Power-On
1. Turn on all the main line switches of the expansion cabinet.
If an optional power cabinet is connected, also turn on all the main line switches
of the power cabinet.
2. Turn on all the main line switches of the base cabinet.
If an optional power cabinet is connected, also turn on all the main line switches
of the power cabinet.
4.5.2.2 Power-Off
1. Turn off all the main line switches of the base cabinet.
If an optional power cabinet is connected, also turn off all the main line switches
of the power cabinet. (Note)
2. Turn off all the main line switches of the expansion cabinet.
Note – Please wait at least 30 seconds before turning on the system power that you
turned off, by using the main line switch or the circuit breakers on the distribution
panel.
4.5.3 Main Line Switch Locations
This section describes the locations of main line switch for each type of power
supply. (See
FIGURE 4-4 through FIGURE 4-9 )
A power cabinet is required when using the dual power feed option. However, in
the case of the SPARC Enterprise M8000 server single-phase and dual power feed,
the power cabinet is not required because the rack-mountable dual power feed
option is mounted in the SPARC Enterprise M8000 server cabinet (See
FIGURE 4-5 ).
In the case of the SPARC Enterprise M9000 server single-phase and dual power feed,
main line switches are mounted in both the SPARC Enterprise server cabinet and the
power cabinet (See
FIGURE 4-8 ).
In the case of the three-phase dual power feed, the main line switch is located in the
power cabinet (See
FIGURE 4-6 and FIGURE 4-9 ).
