14-6 SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
8. From the OS, execute the cfgadm -a command to verify that the status of
CD-RW/DVD-RW drive unit and tape drive unit has changed from "configured"
to "unconfigured."
9. Detach the target CD-RW/DVD-RW drive unit from the port.
From the terminal that is connected to XSCF, log in to XSCF, and execute the
cfgdevice -c detach -p
port no. command.
10. Confirm that the target CD-RW/DVD-RW drive unit is unconfigured from the
domain.
From XSCF, execute cfgdevice -l to confirm that the relevant port is not
displayed in the current connection.
11. Connect the wrist strap clip to a cabinet grounding port, and attach the band of
the wrist strap to one of your wrists.
12. Remove the CD-RW/DVD-RW drive unit to be replaced.
a. Using a Phillips screwdriver, loosen the two knob screws securing the
CD-RW/DVD-RW drive unit to be replaced.
b. While grasping the knob screws, pull out the CD-RW/DVD-RW drive unit
slowly from the slot.
# cfgadm -a
Ap_Id Type Receptacle Occupant Condition
:
c0::dsk/c0t4d0 CD-ROM connected unconfigured unknown
c0::rmt/0 tape connected unconfigured unknown
:
