Figure 4-9 – FUJITSU SPARC ENTERPRISE M8000 User Manual

Page 128

4-34

SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009

4.5.3.6

SPARC Enterprise M9000 Server Three-Phase Power Feed

FIGURE 4-9

Main Line Switch Locations (Power Cabinet)

Note –

Same type of switch is used for main line switches in base cabinet and

power cabinet on a system with three-phase dual power feed.

M9000 three-phase power feed:

-Switch (x5)

-ACS_D

M9000 three-phase power feed

(for dual power feed option):

-Main line switch (x1)

-ACSTPH_A (delta connection)
or ACSTPH_B (star connection)

M9000 three-phase power feed
(for base power feed):

-Main line switch (x1)

-ACSTPH_A (delta connection)

or ACSTPH_B (star connection)

Front

Rear

M9000 three-phase power feed:

-Switch (x5)

-ACS_D
