Chapter 13 PCI Slot Device Replacement 13-17
b. Loosen the two screws at the rear of the PCI cassette, slide out the latch, and
secure it with screws. (See FIGURE 13-4 )
Caution – Do not loosen the screws at the bottom because they are used as a
reference position.
c. Slide the PCI card in the direction of the arrow to remove it. (See FIGURE 13-5 )
7. Mount the replacement PCI card on the PCI cassette. (Perform the work on the
conductive mat.) (See FIGURE 13-6 and TABLE 13-2 )
a. Move the PCI card in the direction of the arrow, and mount it on the PCI
cassette by inserting the part projecting out at the bottom of the bracket of
the PCI card into the hole at the bottom of the front panel of the PCI cassette
and inserting the pin of the PCI cassette into the oval hole at the top of the
bracket of the PCI card. (See
FIGURE 13-7 )
b. Push the PCI card until the notched part on the base plate of the PCI card
touches the card-positioning tab from the PCI cassette.
c. Set the screws in the center part of each of the two latches, and then tighten
the screws while pressing them against the PCI card.
Note – When affixing the PCI card after aligning its position with the
card-positioning tab, do so while pulling the lever about 2 cm from the frame.
Caution – If the card is short, move the screw at the bottom of the cassette as
required. In such cases, place the latches as close as possible to the far end of the
card. (See
FIGURE 13-9 )
8. Mount the PCI cassette.
a. Pull the lever of the PCI cassette until the PCI cassette is pulled out
completely.
b. Align the PCI cassette with the groove of the PCI slot, and insert the PCI
cassette.
c. Press the upper part of the cassette until the cassette is inserted in the same
position as the other cassettes.
d. Push in the lever.
e. Using a Phillips screwdriver, tighten the green screw.
