FUJITSU SPARC ENTERPRISE M8000 User Manual
Page 338
18-2
SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
An ACS distributes AC input power from external sources to power supply units
(PSUs). If the dual power feed option is not installed, a main line switch is mounted
in an ACS. An ACS can be duplicated, but active replacement cannot be performed
even in such a case.
,
, and
show the mounting locations of CMUs.
FIGURE 18-1
ACSs Mounting Locations (Rear of the M8000)
ACS_A
