Figure 9-1 – FUJITSU SPARC ENTERPRISE M8000 User Manual
Page 232
9-2
SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
For details of the types and locations of power supply, see
“Power-On/Off of Main Line Switch” on page 4-24
FIGURE 9-1
PSU Mounting Locations (Front of the M8000 + Power Cabinet)
Power cabinet
Power supply unit
PSU#0-#8
#8
#7
#6
#5
#4
#3
#2
#1
#0
PSU#10-#19
#19
#18
#17
#16
#15
#14
#13
#12
#11
#10
