5-1

C H A P T E R

5

Internal Components Access

This chapter explains how to access each unit of the server, in the following sections:

Section 5.1, “How to Open and Close Doors” on page 5-1

Section 5.2, “Corresponding Components and Doors That Can Be Accessed” on
page 5-2

Section 5.3, “How to Remove a Door” on page 5-3

Section 5.4, “How to Remove a Side Panel” on page 5-4

5.1

How to Open and Close Doors

The high-end server is equipped with doors at the front and rear. The operator panel
can be operated and checked when the doors are closed, but, to replace the operator
panel or to access or maintain other components, the doors must be opened.

However, the backplane cannot be accessed by only opening a door. It cannot be
accessed unless some units and working parts connected to it are removed.

As shown in

FIGURE 5-1

, each door can be opened and closed by inserting a key into

the handle lock and turning the handle. Borrow the key from the system
administrator.

Note –

There are two types of key: one for the doors of the server and the other for

the operator panel. Both are managed by the system administrator.

The detailed procedure below explains how to open a door. The same procedure
applies to both the front and rear doors.

1. Insert the key into the lock above the handle, and turn it clockwise 90 degrees.
