Chapter 17
Crossbar Unit Replacement
17-7
Caution –
If you are unable to obtain a torque screwdriver, finger tighten the clock
cable connectors. Do not secure them with a regular screwdriver.
Caution –
Do not secure the clock cables to the cable folder along with the data
cables, and lay the clock cables on the data cables.
13. Return the top and bottom cable support brackets (in front of the replacement
crossbar unit) to their original positions in their respective upper and lower
holes to securely affix them.
Note –
Visually check from the opening in the upper cover to ensure that the two
printed circuit boards do not come into contact with the cable.
14. Switch on all main line switches for the AC section (ACS) in the power supply
system.
15. Confirm that the XSCF STANDBY LED (green) on the operator panel remains
lit. If it is blinking, wait until it remains lit.
16. Start (turn on power) all domains together. Take either of the following two
actions:
■
Press and hold down (for less than four seconds) the POWER switch on the
operator panel.
■
From a console that is connected to XSCF, execute the poweron -a command
of XSCF.
The power to all the domains is turned on, and then the power-on self test (POST)
is executed. When ok prompt displayed on the console of relevant domain, POST
is completed.
For details of the power-on operation, see
Section 4.4.2, “Powering the Server On”
, and the SPARC Enterprise M3000/M4000/M5000/M8000/M9000
Servers XSCF User’s Guide.
17. Confirm that the replacement components are normal by using the
showhardconf
or showstatus command of XSCF.
Unless "*" is displayed for the replacement XBU, it is operating normally.
For details of the showhardconf command and showstatus command, see the
SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF User’s Guide,
the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF Reference
Manual, or the man page.
