In cold replacement, none of the replacement work is performed with the
maintenance menu from a terminal connected to XSCF.
20.2.1 M8000/M9000 BPs
FIGURE 20-1 , FIGURE 20-2 , and FIGURE 20-3 show the mounting locations of BPs of
M8000, BP for M9000 (base cabinet), and M9000 (with the expansion cabinet),
respectively.
FIGURE 20-1 BP Mounting Locations (Rear of the M8000)
BP_A
