22-6 SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
Caution – After stopping all the domains, be sure to switch off the main line
switches in the power supply system to completely shut off the supply of power.
6. Connect the wrist strap clip to a cabinet grounding port, and attach the band of
the wrist strap to one of your wrists.
7. Remove the following components so that you can access the MEDBP to be
replaced.
M8000 (See FIGURE 22-4 ):
a. Remove the tape drive unit. (See Chapter 15 )
b. Remove the CD-RW/DVD-RW drive unit. (See Chapter 14 )
c. Using a Phillips screwdriver, loosen the two retaining screws to remove the
partition box located between the CD-RW/DVD-RW drive unit and XSCFU.
d. Remove the two XSCFUs. (See Chapter 11 ) If any cable is connected, remove
it.
M9000 (See FIGURE 22-5 ):
a. Remove the tape drive unit. (See Chapter 15 )
b. Remove the CD-RW/DVD-RW drive unit. (See Chapter 14 )
c. Remove I/O units #0, #2, and #4 (IOU#0, IOU#2, and IOU#4) on the right side
of the CD-RW/DVD-RW drive unit. A filler panel may be mounted
depending on the option configuration. (See
Chapter 7 )
8. Remove the MEDBP to be replaced.
a. Using a Phillips screwdriver, loosen the two thumb screws securing the
MEDBP.
b. Slide the MEDBP to the right.
c. Disconnect the two cables connected to the rear of the MEDBP.
Note – Be sure to press both lock release buttons inward and pull the connector
when removing the SAS cable (lock release buttons of the connector are yellow).
d. Along the guide, and remove MEDBP carefully
