15-10 SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
7. Connect the wrist strap clip to a cabinet grounding port, and attach the band of
the wrist strap to one of your wrists.
8. Remove the tape drive unit to be replaced. (See FIGURE 15-4 or FIGURE 15-5 )
a. Using a Phillips screwdriver, loosen the two knob screws securing the tape
drive unit.
b. While grasping the knob screws, pull out the tape drive unit slowly from the
slot.
9. Place the removed tape drive unit on an antistatic conductive mat.
10. Mount the replacement tape drive unit by following the removal instructions
in Step 8 in reverse order.
Caution – Do not forcibly push the tape drive unit in when inserting it. If the tape
drive unit is forcibly inserted despite the presence of any obstruction in a slot or any
problems with the connector pin, serious damage may result.
11. Attach the tape drive unit to the port.
Execute the cfgdevice -c attach -p <port no.> command of XSCF.
12. Confirm that the replacement tape drive unit is configured to the domain.
From XSCF, execute the cfgdevice -l command to confirm that the specified
port number is displayed in the current connection.
13. Turn on the power to the relevant domain.
From a console that is connected to XSCF, execute the poweron -d command of
XSCF.
For details of the power-on operation, see Section 4.4.2, “Powering the Server On”
on page 4-19 , and the SPARC Enterprise M3000/M4000/M5000/M8000/M9000
Servers XSCF User’s Guide.
14. Start up domains as necessary.
15. Close the door on the server and lock it.
15.4 Cold Replacement
The procedure is as follows.
