15-12

SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009

9. Mount the replacement tape drive unit by following the removal instructions

in reverse order.

Caution –

Do not forcibly push the tape drive unit in when inserting it. If the tape

drive unit is forcibly inserted despite the presence of any obstruction in a slot or any
problems with the connector pin, serious damage may result.

10. Switch on all main line switches for the AC section (ACS) in the power supply

system.

11. Confirm that the XSCF STANDBY LED (green) on the operator panel remains

lit. If it is blinking, wait until it remains lit.

12. Start (turn on power) all domains together. Take either of the following two

actions:

■

Press and hold down (for less than four seconds) the POWER switch on the
operator panel.

■

From a console that is connected to XSCF, execute the poweron -a command
of XSCF.

For details of the power-on operation, see

, and the SPARC Enterprise M3000/M4000/M5000/M8000/M9000

Servers XSCF User’s Guide.

13. Start the domain as necessary.

14. Restore the original mode switch setting on the operator panel.

Note –

When the maintenance work is completed, be sure to confirm the mode

switch setting and return the switch to Locked.

15. Close the door on the server, and lock it.
