2-16

SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009

■

Removing an I/O unit (IOU)

2.3

Operator Panel

The operator panel controls the high-end server power. The operator panel is usually
locked with a key to prevent the server from being mistakenly powered off through
an operator error during system operation.

Before starting maintenance work, ask the system administrator to unlock the
operation panel.

2.3.1

Operator Panel Location

FIGURE 2-12

indicates the location of the operator panel (OPNL) of the high-end

servers. The expansion cabinet is not equipped with the operator panel.
