4-24 SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
Output for the showhardconf command (Continued)
Refer to the showhardconf man page for more information.
2. Verify the state of the status LEDs on the FRU.
Refer to TABLE 2-11 and TABLE 2-12 for LED status.
4.5 Power-On/Off of Main Line Switch
4.5.1 Types of Power Supply
TABLE 4-1 shows how the components of the server vary depending on the type of
power supply. For details on the electrical specifications, see the SPARC Enterprise
M8000/M9000 Servers Site Planning Guide.
FAN_A#4 Status:Normal; Serial:PA0605B297;
+ FRU-Part-Number:CA06501-D023 A2 /371-2222-00 ;
:
FAN_A#9 Status:Normal; Serial:PA0605B300;
+ FRU-Part-Number:CA06501-D023 A2 /371-2222-00 ;
:
SWBP#0 Status:Normal; Ver:0101h; Serial:PP0607E759 ;
+ FRU-Part-Number:CA20394-B16X 001AA ;
MEDBP#0 Status:Normal; Ver:0101h; Serial:PP06058497 ;
+ FRU-Part-Number:CA20394-B17X 002AB ;
TABLE 4-1 Types of Power Supply and the Components of the Server
Model
Types of power supply
Components of the server
Reference diagram
AC input power Single/Dual power
M8000 Single-phase Single power Single-phase power feed option See FIGURE 4-4 .
Single-phase Dual power Rack-mountable dual power feed option See FIGURE 4-5 .
Three-phase Dual power Power cabinet + three-phase power feed
option See FIGURE 4-6 .
