FUJITSU SPARC ENTERPRISE M8000 User Manual
Page 294
13-20
SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
Caution –
After stopping all the domains, be sure to switch off the main line
switches in the power supply system to completely shut off the supply of power.
6. Connect the wrist strap clip to a cabinet grounding port, and attach the band of
the wrist strap to one of your wrists.
7. Remove the PCI cassette of the PCI card to be replaced.
Caution –
To disconnect the link cable, which is a cable connected between the link
card mounted on the server and external I/O expansion unit, pull the latch lock of
the connector. If you forcibly pull the connector or the cable, the cable may be
damaged.
Caution –
When removing cables such as LAN cable, if your finger can't reach the
latch lock of the connector, press the latch with a flathead screwdriver to remove the
cable. Forcing your finger into the clearance can cause damage to the PCI card.
a. Using a Phillips screwdriver, loosen the green screw securing the lever.
b. While grasping the upper part of the PCI cassette, pull the lever until it is
stopped, and continue pulling it to pull out the PCI cassette.
c. Place the removed PCI cassette on an antistatic conductive mat.
8. Remove the PCI card from the PCI cassette. (Perform the work on the
conductive mat.)
a. While grasping the lock bracket, turn it in the direction of the arrow and
push the lever a little. Then, push in the lever completely. (See
Once you start moving the lever, the lock bracket need not be held.
b. Loosen the two screws at the rear of the PCI cassette, slide out the latch, and
secure it with screws. (See
Note –
Do not loosen the screws at the bottom because they are used as a reference
position.
c. Slide the PCI card in the direction of the arrow to remove it. (See
9. Mount the replacement PCI card on the PCI cassette. (Perform the work on the
conductive mat.)
