23-4 SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
FIGURE 23-3 SWBP Mounting Locations (Front of M9000 with the Expansion Cabinet)
TABLE 23-1 lists the abbreviated names and numbers of the SWBPs.
TABLE 23-1 Abbreviated Names and Numbers of SWBPs
Model name Abbreviated names and numbers
M8000 SWBP
M9000 with the base cabinet SWBP
M9000 with the expansion cabinet (base cabinet side) SWBP#0
M9000 with the expansion cabinet (expansion cabinet side) SWBP#1
SWBP#0
SWBP#1
Base cabinet
Expansion cabinet
