FUJITSU SPARC ENTERPRISE M8000 - Manual (Page 258)

11-6 SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
FIGURE 11-4 Initial Page of the Maintenance Menu
Note – DDC_A is displayed only for the M8000
b. From the replacement parts list on the maintenance menu, select 4, "XSCFU."
c. From here, perform the operation according to the guidance displayed in the
maintenance menu.
Check the states of LEDs (POWER LED: off; CHECK LED: blinking) on the
XSCFU to be replaced, and begin the actual replacement work when a message
instructing the user to replace the target XSCFU is displayed. Leave the
maintenance menu as is until
Step 5 .
4. Connect the wrist strap clip to a cabinet grounding port, and attach the band of
the wrist strap to one of your wrists.
5. For the M9000 (with the expansion cabinet), disconnect the cables from all
connectors of the XSCFU to be replaced.
6. Remove the XSCFU to be replaced.
a. If the SPARC Enterprise M9000 server expansion cabinet is installed, slide
the cable support bracket at the front of the XSCF unit up or down by one
hole, and then remove the cable connected to the XSCF unit.
b. Using a Phillips screwdriver, turn the knob screws securing the upper and
lower eject/lock levers (in the SPARC Enterprise M8000 server) or left and
right eject/lock levers (in the SPARC Enterprise M9000 server) 90 to 180
degrees to unlock the levers. (Turn the knob screw while lightly pulling the
lever.)
c. Unlock the eject/lock levers to pull the XSCFU off the backplane.
d. While grasping the eject/lock levers, pull out the XSCFU slowly from the
slot.
---------------------------------------------------
Maintenance/Replacement Menu
Please select a type of FRU to be replaced.
1. CMU/IOU(CPU Memory Board Unit/IO Unit)
2. FAN(Fan Unit)
3. PSU(Power Supply Unit)
4. XSCFU(Extended System Control Facility Unit)
5. DDC_A(DDC for BP_A)
---------------------------------------------------
Select [1-5|c:cancel] :
