D.7 upc port, Upc port – FUJITSU SPARC ENTERPRISE M8000 User Manual
Page 501
Appendix D
UPS Controller
D-7
D.7
UPC Port
This chapter describes the location of the UPC port and the UPS connections.
■
UPC#0 connects with UPS#0. UPC#1 connects with UPS#1.
■
The single power feed uses UPC#0 only.
■
The dual power feed option uses UPC#0 and UPC#1.
show the location of the UPC port in the main unit.
FIGURE D-3
UPC Port of SPARC Enterprise M8000/M9000 Server
UPC#1
UPC#0
SPARC Enterprise M8000 Server
SPARC Enterprise M9000 Server
(Front View)
(Front View)
