13-18
SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
Caution –
Align the PCI card with the slot guides, insert it carefully, and secure it
firmly.
Caution –
Do not forcibly push the PCI card when inserting it, even if it is not
moving smoothly. If the PCI card is forcibly inserted despite the presence of any
obstruction in a slot or any problem with a connector pin, serious damage may
result.
■
If the lever of a PCI cassette cannot be inserted:
a. When the lever of the PCI cassette is pushed in but it stops halfway without
reaching the far end, do not forcibly push it in any further. Instead, pull it
out once and then insert it again. (See
b. If the lever stops halfway even when the PCI cassette is inserted again, pull
the PCI cassette out from the IOU, and then check whether the PCI card is
set in the normal position (see a, b and c of
). Then, reinsert the PCI
cassette.
Caution –
Do not forcibly push the lever of the PCI cassette when the lever is
pushed but stops halfway. In this case, restore the lever to its original position, and
then reinsert it. If the lever stops halfway even when the PCI cassette is inserted
again, it is possible that the PCI card is not set in the normal position (see a, b and c
of step 7). Pull the PCI cassette out from the IOU, check the position of the PCI card,
and then reinsert it.
9. Turn on power to the relevant domain.
From a console that is connected to XSCF, execute the poweron -d command of
XSCF.
The power to all the domains is turned on, and then the power-on self test (POST)
is executed. When ok prompt displayed on the console of relevant domain, POST
is completed.
For details of the power-on operation, see
Section 4.4.2, “Powering the Server On”
, and the SPARC Enterprise M3000/M4000/M5000/M8000/M9000
Servers XSCF User’s Guide.
10. Close the door on the server, and lock it.
