4-40 SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
3. Bind the cables connected to each external I/O expansion unit with a short
hook-and-loop fastener. (See (1) in FIGURE 4-12 .)
Caution – Keep optical fiber cables as far apart from other cables as possible to
prevent the optical fiber cables from being covered by the other cables.
4. Bind the bundles of cables with a long hook-and-loop fastener at location (2)
shown in FIGURE 4-12 while taking care not to touch the main line switch of the
ACS.
5. Fasten the bundles of cables with a long hook-and-loop fastener to the cable
holder at location (3) shown in FIGURE 4-12 while taking care not to touch the
main line switch of the ACS.
