Figure 4-5 – FUJITSU SPARC ENTERPRISE M8000 User Manual
Page 124
4-30
SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
4.5.3.2
SPARC Enterprise M8000 Server Single-Phase and Dual
Power Feed
FIGURE 4-5
Main Line Switch Locations (Rear of the M8000)
M8000 single-phase and
dual power feed:
-Main line switch (x3)
-ACS_A
M8000 single-phase and
dual power feed:
-Main line switch (x3)
-ACS_C
