FUJITSU SPARC ENTERPRISE M8000 User Manual
Page 154
6-2
SPARC Enterprise M8000/M9000 Servers Service Manual • August 2009
For the version matching of firmware, see the SPARC Enterprise
M3000/M4000/M5000/M8000/M9000 Servers XSCF User’s Guide.
,
, and
show the mounting locations of CMUs in the
high-end server cabinets.
FIGURE 6-1
CMU Mounting Locations (Front of the M8000)
CMU#3
CMU#2
CMU#1
CMU#0
