Tutorial
Profile LVS Event Management System Instruction Manual
2-9
ACG.. E/E of record images are output to the output connector connected
through the EE channel, and play images are output to the output connector
connected through the PB channel.
6. Assign timecode sources.
a. Click Timecode Routing to open the Timecode Routing tab (See
Figure 2–8).
For each resource group, you can record either VITC or LTC from an
external source along with the audio and video. Timecode from the
internal timecode generator is always recorded.
For timecode signal input, either LTC input or VITC can be selected.
For each resource, you can choose to output VITC, LTC, or both.
Figure 2-8: Timecode Routing Tab  Configuration Window
When no material is being played back, the input VITC and LTC are sent
directly to the output , although they are slightly delayed. When recorded
material is being played back, the recorded timecodes can be output as
VITC , LTC or both. The internal generator is always connected to the
resource. If neither VITC nor LTC is connected to the input channel of a
resource, timecode output through the external channel will be unpre-
dictable when playing back.
Timecode Source
