Lever Adjustment
8-6
Profile LVS Event Management System Instruction Manual
To adjust the REV SPRING position, proceed as follows:
11. Move the lever backward while pressing and holding the lever button until
the lever stops.
12. Release the lever. This causes the lever to move forward automatically to
the REV SPRING position.
13. Press CONT.
Pressing CONT causes the instrument to adjust the REV SPRING position.
The following message appears:
[STEP 6]
1. Move lever to position MAX REV.
2. Push CONT key.
To adjust the MAX REV position, proceed as follows:
14. Move the lever backward until it stops.
15. Press CONT.
Pressing CONT causes the instrument to adjust the MAX REV position.
If adjustments have completed successfully, the following message appears:
**** COMPLETE ****
Push CONT key for starting system
Press CONT to quit the lever adjustment routine and to start the Live Controller.
REV SPRING Position
MAX REV Position
