The upper part of the Live Controller display shows the information related to
record functions.
RECORDER
1ch VDR NEAR END OF DISK REMAIN 10H50M
01:30:45:23 REC SA007 PR.00.00
PLAYER
Figure 6-17: Recorder Status Indication (Upper LCD)
The recorder status items listed in Table 6–2 are displayed in left–to–right,
top–to–bottom order in the upper LCD screen.
Table 6-2: Recorder Status
Item/Status (in Top Row)
Display/Description
Recording mode
Continue/1ch VDR/Lnr VTR
(2 ch, 1 ch, VTR resource groups, respectively)
Warning message
NEAR END OF DISK / END OF DISK / OFF LINE/NAK
Disk Remaining
REMAIN xxHxxM
Current Timecode in recording
xx:xx:xx:xx
Item/Status (in bottom Row)
Display/Description
Recording status
REC/STOP
Reserved scene number
Sxxx
Number of next scene to be created.
Current Preroll Time
PR.xx.xx (where xx.xx is sec.frame)
When the line is not connected, OFF LINE is displayed.
RECORDER Status
