Recording Mode
1-10
Profile LVS Event Management System Instruction Manual
1-Channel Mode
The 1–channel mode is used when operations which mimic a VTR are desired.
One physical channel is used as both a record and play channel. Note that when
playback is required, recording must end.
This channel is used for recording or playing, repeating record and play
operations in turn (See Figure 1–6.). This provides the same features as
conventional VTR recording. However, the system supports the dedicated Live
Controller, which provides you with features unique to the nonlinear nature of
the Profile PDR, including Highlight search, Time search, and Event control.
Record or play operations can be done with one channel. With a 4–channel
Profile PDR, simultaneous recording of material from 4 cameras is possible.
Record and
Play Channel
REC MARK ENTER/CUEĂUP ENTER/CUEĂUP REC
PLAY/VAR/SHUTTLE PLAY/VAR/SHUTTLE
Recording Scene Playing Scene Recording Scene Playing Scene
Figure 1-6: Example of Repeating Record/Play Operations
