Grass Valley LVS 100 v.3.15 - Manual (Page 195)

Timeline Window
Profile LVS Event Management System Instruction Manual
4-77
5. Enter –1 second in the Adjust In text box.
6. Click the Change button.
ACG.. When you move the IN point of the first event on the timeline to a later
time, BLACK will be inserted before the IN point.
Voice Button 
Invokes the voice–over function. Refer to Voice–Over Function
on page 4–80 for more information.
Clear Button 
Clears all events on the timeline. The Confirmation dialog box
opens, allowing you to confirm that you really want to clear all events from the
timeline by clicking the Yes button.
Zoom Buttons 
Zooms in and out on the timeline track display.
Undo 
Restores a previous edit state. Refer to Undo on page 4–71 for more
information.
Figure 4–34 and 4–36 show the Timeline Display tab in the Timeline Window.
Play Area / Timeline Bar 
The bar displayed in highlighted green represents the
total duration to be played back.
Current Playback Point 
The bar displayed in pink represents the duration
that has been played back. The rightmost point of the pink area is the current
playback point.
Cue up Point 
Clicking on an arbitrary point on the bar allows the LVS to
cue up at that point.
Video Check Box 
Enables editing on the video track. When the check box is
cleared, you can no longer edit on the video track.
Audio Check Boxes 
Enable editing on the audio tracks. When the check boxes
are cleared, you can no longer edit on the corresponding audio tracks.
Timeline Display Tab
