Grass Valley LVS 100 v.3.15 - Manual (Page 171)

Playlist Window
Profile LVS Event Management System Instruction Manual
4-53
1. To set the gang roll master in the Playlist Window, open the slave Playlist
Window and select the channel to be designated as a master in the
drop–down list box in the GANG ROLL panel.
To set the gang roll master in the Current Resource Information window,
click the Gang Roll button in the slave panel, then select the master channel
using the drop–down list box in the GANG ROLL panel.
GANG ROLL panel
Click on this button to
displaythe Gang Roll
panel
CHECK
button
SET Check box
Combo box
Figure 4-32: Gang Roll Function on the Current Resource Information window
2. Once the master and slave have been selected, check the SET check box of
the GANG ROLL panel in the Playlist Window or Current Resource
Information window. Gang roll wll remain in effect as long as SET is
selected.
You can compare the number of events and their duration between the two
Playlists. With the master and slave selected, click on the CHECK button in the
GANG ROLL panel to display the results. You can clear the results by clicking
on the CHECK button again.
