Recording Mode
Profile LVS Event Management System Instruction Manual
1-11
VTR Emulation Mode
The VTR emulation recording mode is equivalent to a VTR recording. It
requires one Profile physical channel to record and play scenes. This recording
mode is provided to support Sony DTR–3000. In this mode, you cannot use a
Live Controller with this system.
The Sony DTR-3000 is supported. However, only limited support of LVS
features are available, including immediate cue–up and the ability to respond by
random access. (See Figure 1–7.)
REC MARK SEARCH SEARCH RECĂSTOP REC
PLAY/VAR/SHUTTLE
PLAY/VAR/SHUTTLE
MARK
Recording Scene Playing Scene Recording Scene Playing Scene Record and
Play Channel
Figure 1-7: Example of VTR Emulation Mode
Features
