Preparation for Use
7-6
Profile LVS Event Management System Instruction Manual
Selection is made as follows.
1. Enter the diagnostic routine and display the Main menu.
a. Turn the Power on while holding the EVENT and TIME buttons. The
following menu appears on both upper and lower LCDs of the Live
Controller.
**** DIAG ****
CONT: Starting tests or configure.
0: Starting up the system.
b. Press the CONT key. The following Diagnostic Main menu appears.
[MAIN MENU]
0: Exit menu.
1: MEMORY2: RS422 3: KEY
/LED 4: LCD
5: SLNID/ADC/ENCDR/CLTCH 6: S-E2PROM
SEARCH: KEYPLACE SELECT
2. Change the key configuration.
a. Press SEARCH to bring up the KEY PLACE SELECTION menu on the
LCDs.
[KEYPLACE SELECTION]
IN : Standard key place.
OUT : NBC key place.
b. Press
IN if you want to select the Standard key configuration, or press
OUT if you want to select the Other key configuration.
Key Configuration
Selection
