Timeline Window
4-60
Profile LVS Event Management System Instruction Manual
Timeline Overview
ACG.. When you are recording on two or more channels and performing timeline
editing, you should set the compression target to 75 KByte Per Field or less in
the Configuration window. Higher values may cause black to be recorded.
This section describes the following operations:
1. Adding and/or inserting scenes at arbitrary positions on the timeline.
2. Editing events in various modes.
3. Creating packaged timelines by adding timeline lists to the Highlight
Window.
It also explains how to create another packaged timeline from an existing
packaged timeline by:
4. Copying a packaged timeline back into the Timeline window.
5. If necessary, adding and/or inserting other scenes at arbitrary position on the
timeline.
6. As required, editing events in various modes.
7. Creating a new packaged timeline by adding timeline list to the Highlight
window.
Setting Target Time
You should specify the total duration of the timeline. This setting can be changed
at any time.
1. Click on the Set button to open the Target Time dialog box. See Figure
4–35.
2. Enter timecode for total duration in the form of Hours:Minutes:Se-
conds:Frames.
3. Click on the OK button to make the input target time effective and close the
dialog box.
While this dialog box is open, you cannot perform any other operations in the
Timeline Window.
