Grass Valley LVS 100 v.3.15 User Manual
Page 312
Removal and Installation Procedures
9-22
Profile LVS Event Management System Instruction Manual
Spacer Post M2.6,
12.5 mm 4
ScrewM3 10mm,
FLH 2
FlatĆbladed
Screwdriver
Power Switch
RFI Filter
FlatĆbladed
Screwdriver
FUSE BOX REMOVAL
POWER SWITCH REMOVAL
Figure 9-12: Power Switch, RFI Filter and RSĆ422 Connectors Removal (Outside View)
