Timeline Window
Profile LVS Event Management System Instruction Manual
4-85
Timeline Operation with the Live Controller
If you wish to use the Live Controller to control the Timeline window, you must
assign an RS–422 port to the Timeline resource in the Resource Setup tab in the
Configuration window.
A Group: the 2Channels resource is assigned to VDR1 of the Live Controller.
B Group: the Timeline resource is assigned to VDR2 of the Live Controller.
In this example, you would press VDR2 button on the controller to control the
Timeline window. This will cause TIMELINE to appear in the Live Controller
display.
Cue up and Playback.
Drag and drop some scenes into the Timeline window.
1. Press the EVENT, 1, and SEARCH buttons in succession on the Live
Controller.
The first scene on the Timeline will be cued up.
2. Once the scene has been cued up, the PLAY, STOP, JOG and SHTL buttons
can be used on that scene.
3. If you want to cue up third scene of the Timeline; press EVENT, 3 and
SEARCH.
Change Duration
To change the duration of a scene in the Timeline, double–click the scene to open
the Preview window. In the Preview window:
1. Select Playback Resource to be monitored during preview operation. Be sure
to select select the corresponding control channel, either VDR1 or VDR2.
2. Use the PLAY, STOP, JOG, and SHTL buttons to determine the new IN and
OUT points.
3. Press the SAVE button to close the Preview window. The new duration of
the scene is shown in the Timeline window.
Example
