Mounting and Wiring Information Specific to Frames B, C, D, E, F, G, and H

4-9

The terminal blocks provide the following:

The voltage clearance provides physical space between the logic earth
ground and other signals on the terminal block.

This

terminal

block:

Provides these terminal

numbers:

Which provide access to this signal:

TB10

6, 9, 12, 17, 20

Shield ground

1, 2, 3

DC power supply

± 10V DC

50 mA per voltage

4, 5, 7, 8

0 to

±10V DC Input

Input impedance = 20K Ohms

10, 11

4 – 20 mA input

Input impedance = 130 Ohms

13, 14

Pulse input for frequency reference

+5V DC — Jumper J4 Set to 1 – 2

+12V DC — Jumper J4 Set to 2 – 3

Scale Factor (Pulse PPR) must be set

10mA minimum

15, 16, 18, 19

0 to

±10V DC output

Output impedance = 100 Ohms, 10mA maximum

21, 22

4 – 20 mA DC output

Output impedance = 20 Ohms

TB11

Logic Earth Ground, Shield

1, 2, 3,

Programmable contacts

4, 5, 6,

Resistive rating = 115VAC/30VDC, 5.0A

7, 8, 9

Inductive rating = 115VAC/30VDC, 2.0A
