Page 258

11-60
Parameters
196
Drive/Inv Sts 2
Use Drive/Inv Sts 2 to view the status/conditions within the drive.
When a bit is set (1), the corresponding condition in the drive is
true.
1 Drive/Inv Sts 2 was added in Version 2.xx.
When set, the bits are defined as the following:
Parameter number
File:group
Monitor:Drive/Inv Status
Parameter type
source
Display
bits
Factory default
not applicable
Minimum value
00000000.00000000
Maximum value
11111111.11111111
Conversion
1 = 1
Bit
Description
0
Flux Ready
The motor is ready to be fluxed
up.
1
Flux Up
The motor is fluxed up.
2
DC Braking
DC braking is currently being
used.
3
Reserved
Leave 0.
4
Bus Ridethru
The drive is in a bus ridethrough
condition.
5
Jogging
The drive is jogging.
Bit
Description
6
Searching
Flying start is syncing with motor.
7
Enc TrimLoss
Indicates encoder loss when
using Encoder switchover mode
8
At Limit
The motor is at the At Limit set
point.
9
Func Output
Function Output 1
(parameter 213) and/or Function
Output 2 (parameter 214) is non-
zero.
10 – 11 Reserved
Leave 0.
Bit
Description
12
Relay Setpt1
Relay 1 has reached Relay
Setpoint 1 (parameter 115).
13
Relay Setpt2
Relay 2 has reached Relay
Setpoint 2 (parameter 188).
14
Relay Setpt3
Relay 3 has reached Relay
Setpoint 3 (parameter 190).
15
Relay Setpt4
Relay 4 has reached Relay
Setpoint 4 (parameter 192).
197
Logic Cmd Input
Use Logic Cmd Input to change the logic evaluation block. The
bits that you change here are reflected in Logic Input Sts
(parameter 14).
1 Logic Cmd Input was added in Version 2.xx.
The bits are defined as follows:
Parameter number
File:group
none
Parameter type
linkable destination
Display
bits
Factory default
00000000.00000000
Minimum value
00000000.00000000
Maximum value
11111111.11111111
Conversion
1 = 1
Bit
Description
0
Normal Stop
A ramp stop is selected.
1
Start
A start is in progress.
2
Jog 1
A jog 1 is in progress.
3
Clear Fault
A clear fault is in progress.
4
Forward
A forward was commanded.
Bit
Description
5
Reverse
A reverse was commanded.
6
Jog 2
A jog 2 is in progress.
7
Cur Lim Stop
A current limit stop is
selected.
8
Coast Stop
A coast stop is selected.
9
Spd Ramp Dis
Ramps are disabled.
Bit
Description
10
Flux Enable
Flux is enabled.
11
Process Trim
Process trim is enabled.
12
Speed Ref A
13
Speed Ref B
14
Speed Ref C
15
Reset Drive
The drive has been
commanded to reset.
C B A
0 0 0 No Charge
0 0 1 Speed Ref 1
0 1 0 Speed Ref 2
0 1 1 Speed Ref 3
1 0 0 Speed Ref 4
1 0 1 Speed Ref 5
1 1 0 Speed Ref 6
1 1 1 Speed Ref 7
