11-38
Parameters
117
L Option In Sts
Use L Option In Sts to view the status of the L Option inputs.
Parameter number
File:group
Interface/Comm:Digital Config
Parameter type
source
Display
bits
Factory default
not applicable
Minimum value
00000000.00000000
Maximum value
00000001.11111111
Conversion
1 = 1
Bit
Description
Bit
Description
Bit
Description
Bit
Description
0
TB3-19
3
TB3-23
6
TB3-27
9 – 15 Reserved
1
TB3-20
4
TB3-24
7
TB3-28
Leave 0.
2
TB3-22
5
TB3-26
8
TB3-30 (enable)
118
Mop Increment
Use Mop Increment to set the rate of increase or decrease to the
Manually Operated Potentiometer (MOP) value based on
rpm/second. Mop Increment is only used when the value of
L Option Mode (parameter 116) is 5, 9, 10, or 15.
Parameter number
File:group
Interface/Comm:Digital Config
Parameter type
linkable destination
Display
x.x rpm (rpm/second)
Factory default
10% of base motor speed
Minimum value
0.0
Maximum value
base motor speed
Conversion
4096 = base motor speed
Refer to Chapter 9, Applications, for more information.
119
Mop Value
Use Mop Value to view the Manually Operated Potentiometer
(MOP) value. You need to link Mop Value to a reference, such as
Speed Ref 1 (parameter 29) for the drive to follow the Mop
command for speed.
Parameter number
File:group
Interface/Comm:Digital Config
Parameter type
source
Display
±x.x rpm
Factory default
not applicable
Minimum value
0.0
Maximum value
base motor speed
Conversion
4096 = base motor speed
Refer to Chapter 9, Applications, for more information.
120
Pulse In PPR
Use Pulse In PPR to set the number of pulses per revolution.
Parameter number
File:group
Interface/Comm:Digital Config
Parameter type
destination
Display
x PPR
Factory default
1024
Minimum value
500
Maximum value
20000
Conversion
1 = 1
Refer to Chapter 7, Setting Up the Input/Output, for more
information.
121
Pulse In Scale
Enter the value to use to scale the pulse input. The scale is a
ratio. For example, you would enter 0.5 if you want to scale the
pulse input to half.
Parameter number
File:group
Interface/Comm:Digital Config
Parameter type
destination
Display
x.xx
Factory default
1.00
Minimum value
0.01
Maximum value
10.00
Conversion
100 = 1.00
Refer to Chapter 7, Setting Up the Input/Output, for more
information.
