Parameters
11-41
127
Clr Flt/Res Mask
You can use the lower byte of Clr Flt/Res Mask (bits 0 through 7)
to select which SCANport devices can issue a Reset Drive
command. You can use the higher byte (bits 8 through 15) to
select which SCANport devices can issue a Clear Faults
command. You can choose between:
0 = Disable control
1 = Enable control
The bits are defined as follows:
Parameter number
File:group
Interface/Comm:SCANport Config
Parameter type
linkable destination
Display
bits
Factory default
11111111.11111111
Minimum value
00000000.00000000
Maximum value
11111111.11111111
Conversion
1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit
Description
0
Reset L Opt
Let the L Option board control
resets.
1
Reset SP 1
Let SCANport device 1 control
resets.
2
Reset SP 2
Let SCANport device 2 control
resets.
3
Reset SP 3
Let SCANport device 3 control
resets.
4
Reset SP 4
Let SCANport device 4 control
resets.
5
Reset SP 5
Let SCANport device 5 control
resets.
Bit
Description
6
Reset SP 6
Let SCANport device 6 control
resets.
7
Reset P197
Let Logic Cmd Input
(parameter 197) control resets.
8
ClrFlt L Opt
Let the L Option board control
clear fault commands.
9
ClrFlt SP 1
Let SCANport device 1 control
clear fault commands.
10
ClrFlt SP 2
Let SCANport device 2 control
clear fault commands.
11
ClrFlt SP 3
Let SCANport device 3 control
clear fault commands.
Bit
Description
12
ClrFlt SP 4
Let SCANport device 4 control
clear fault commands.
13
ClrFlt SP 5
Let SCANport device 5 control
clear fault commands.
14
ClrFlt SP 6
Let SCANport device 6 control
clear fault commands.
15
ClrFlt P197
Let Logic Cmd Input
(parameter 197) control clear
fault commands.
128
Dir/Ref Owner
You can use the lower byte of Dir/Ref Owner (bits 0 through 7) to
see which SCANport device currently has exclusive control of the
reference changes. You can use the higher byte (bits 8 through
15) to see which SCANport device currently has exclusive control
of direction changes. You can choose between:
0 = Reference/direction input not present
1 = Reference/direction input present
The bits are defined as follows:
Parameter number
File:group
Monitor Status:SCANport Status
Interface/Comm:SCANport Status
Parameter type
source
Display
bits
Factory default
not applicable
Minimum value
00000000.00000000
Maximum value
11111111.11111111
Conversion
1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit
Description
0
Refer L Opt
The L Option board owns the
reference command.
1
Refer SP 1
SCANport device 1 owns the
reference command.
2
Refer SP 2
SCANport device 2 owns the
reference command.
3
Refer SP 3
SCANport device 3 owns the
reference command.
4
Refer SP 4
SCANport device 4 owns the
reference command.
5
Refer SP 5
SCANport device 5 owns the
reference command.
Bit
Description
6
Refer SP 6
SCANport device 6 owns the
reference command.
7
Refer P197
Logic Cmd Input (parameter 197)
owns the reference command.
8
Direct L Opt
The L Option board owns the
direct command.
9
Direct SP 1
SCANport device 1 owns the
direct command.
10
Direct SP 2
SCANport device 2 owns the
direct command.
Bit
Description
11
Direct SP 3
SCANport device 3 owns the
direct command.
12
Direct SP 4
SCANport device 4 owns the
direct command.
13
Direct SP 5
SCANport device 5 owns the
direct command.
14
Direct SP 6
SCANport device 6 owns the
direct command.
15
Direct P197
Logic Cmd Input (parameter 197)
owns the direct command.
