Parameters

11-29

83

Motor Current

Use Motor Current to view the actual RMS value of the motor
current as determined from the LEM current sensors. This data is
averaged and updated every 50 milliseconds.

Parameter number

83

File:group

Monitor:Motor Status

Parameter type

source

Display

x.x amp

Factory default

not applicable

Minimum value

0.0 amps

Maximum value

6553.5 amps

Conversion

4096 = rated inverter amps

84

DC Bus Voltage

DC Bus Voltage represents the actual bus voltage in volts as
read by the software from an analog input port.

Parameter number

84

File:group

Monitor:Drive/Inv Status

Parameter type

source

Display

x volts

Factory default

not applicable

Minimum value

0 volts

Maximum value

1000 volts

Conversion

1 = 1

85

Motor Voltage

Use Motor Voltage to view the actual line-to-line fundamental
RMS value of motor voltage. This data is averaged and updated
every 50 milliseconds.

Parameter number

85

File:group

Monitor:Motor Status

Parameter type

source

Display

x volt

Factory default

not applicable

Minimum value

0 volts

Maximum value

+3000 volts

Conversion

1 = 1

86

Motor Torque %

Use Motor Torque % to view the calculated value of motor torque
as determined by the drive. The actual value of the motor torque
is within 5% of this value. This data is updated every
2 milliseconds.

Parameter number

86

File:group

Monitor:Motor Status

Parameter type

source

Display

±x.x% trq

Factory default

not applicable

Minimum value

-800.0%

Maximum value

+800.0%

Conversion

4096 = 100.0%
